Bafang Mid Drive Motor Kit 36V 48V 500W-750W 68-100mm DIY Ebike

United States Stock & Fast Delivery
✅Local Service: Germany 2-6 working days fast delivery and local repair.
✅Warranty: 1 year quality warranty for main parts, free repair or replacement if there is any quality problem.
✅Overseas after-sales site: US maintenance point Feature
:
Upgrade:Upgraded IRFB3077 mosfets controller.
Four riding modes:Pure electric mode & human riding model & power assistance & push models. 4 working modes can be switched at will.
Easy Installation:Can be successfully installed into an electric bicycle in just a few time by only a few tools which can remove the crankset and the center shaft, as well as tools for installing this mid-drive motor.
Compatible:It's compatiable with mountain bike,road bike, racing bike ect bikes with 68-73mm bottom bracket. 36V 500W Mid Drive Motor Specification:
Bafang Model:M315 MM G340.500.C
Power:500W
Voltage:36V
Controller Current: 24A
Max speed with Pedal Assistance:40.5km/h
No Load Speed(RPM) :120±6
Load Speed(RPM):113±6
MAX Torque:100N.m
Efficiency: > 78%
PAS SENSOR : Speed Sensor
Reduction Ratio: 1 : 21.9
Motor Operation Temperature:-20℃-45℃
Bafang Controller: Integrated Inside the Motor
Bracket bottom length: 68mm(The bottom bracket shall be 68-73mm)
Certification:CE/EN 14764/ROHS
Waterproof Grade:IPX5
Net Motor Weight: 4.3kg 48V 500W/750W Mid Drive Motor Specification:
Bafang Model:M315 MM G340.500.C/750.C
Power: 500W/750W
Voltage:48V
Controller Current: 18A/24A
Max speed with Pedal Assistance: 40.5km/h/47.5km/h
No Load Speed(RPM) :126±7
Load Speed(RPM):118±6/110±6
MAX Torque: 100N.m
Efficiency: > 78%
PAS SENSOR : Speed Sensor
Reduction Ratio: 1 : 21.9
Motor Operation Temperature:-20℃-45℃
Bafang Controller: Integrated Inside the Motor
Bracket bottom length: 68mm/100mm(The bottom bracket shall be 68-73mm/100mm)
Certification:CE/EN 14764/ROHS
Waterproof Grade:IPX5
Net Motor Weight: 4.3kg Packaging included:
1 * Mid Drive Motor
1 Pair *Mechnical brake lever default ( Pls leave us message if you want to exchange for brake sensors)
1 Pair * Crank
1 Pair * 44T Chainwheel Default (Pls leave us message if you want to get 46T/48T/52T)
1 Set * Thumb Throttle
1 Set * Speed Sensor
1 * Display (Optional)
1 * 4 to 1 Cable
1 * Accessories
1 * User Manual
1 * XT60 battery extension cable(Free)
1* 6V headlight(Free)
1* Wrench tool(Free)
2* 36V250W stickers(Free) If you choose the battery,the battery comes with the charger. If you choose "no battery", the motor kits do not have battery. Thank you. Note: Gear shift sensor is not included. Please contact us if you want it. Thank you. FAQ: Q: How do I know if this mid drive motor fits for my bike?
A: The 68mm mid drive motor fits for the bike with 68mm (2.68inch) - 73mm (2.87inch) wide bottom bracket. The inner diamater of the bracket should be 34-36mm. We'll send extra install accessorries for 73mm bottom bracket. Q: How do I confirm whether I need the brake levers or the brake sensors?
A: If your brakes are hydraulic or you want to use your own brake sensors, you can choose brake sensors. They can connect with your brakes to work directly. Q: Can I install the motor as soon as I receive it?
A: Before installing the motor, please follow the steps in the manual to connect the motor to see if the motor can work normally. If there is any problem, please contact us directly.Thank you. On Apr 6, 2023 at 20:32:31 PDT, seller added the following information:

Returns Accepted for this item if it's within 30 Days
